Simple Beam Analysis

Description of Simple Beam Analysis

Perform structural analysis of any configuration of engineering beam structures quickly and accurately.
-
Easily create beam structures of all kinds of span and support configurations.
-
Quickly set up any number of beam loading scenarios for which to carry out structural analysis.
-
Full support for point loads, moment loads, uniformly-distributed loads as well as triangular or trapezoidal uniformly-varying loads.
-
Instantly view bending moment/shear force diagrams and deflected beam shape for each loading scenario.
-
Get detailed analysis report containing critical values such as maximum sagging/hogging moments, critical shear forces, maximum span deflection and end slope values.
-
Readily export diagrams, reports and matrices for use in other apps or software.
Try it now for free!
Features Highlight
-
Easy beam setup using touch and popup menus.
-
Unit conversion between metric and imperial systems.
-
Simplified setup of unlimited loading scenarios (loadcases) for each beam.
-
Automatic generation of loadcases to BS 8110 standards for R.C Beams (Optional)
-
Quick analysis of all beams and corresponding loadcases.
-
Instant bending moment and shear force diagrams after structural analysis.
-
Instant plotting of deflected shape for each loadcase.
-
Get support reactions within beam drawings.
-
Get max. span deflection/position for each beam span.
-
Magnify or scale deflected shape to emphasize span deflection.
-
Superimpose bending moment/shear force diagrams for all beam loadcases.
-
Evaluate moment, shear, deflection and slope values at any position on beam.
-
Get rich analysis reports containing critical analysis values, checks etc.
-
Export analysis outputs including diagrams and reports to popular file formats.
-
View all matrices generated during structural analysis for all beam loadcases.
-
Copy and paste beams to quickly add/duplicate beams in a project.
-
Create unlimited number of beams concurrently in a project.
-
Fully customizable beam drawings (Change sizes, styles, colors etc) from settings.
-
Light-weight project sizes (typically in KB) to facilitate file saving and sharing.
